Description
Additionally, the mount has manual height and depth adjustment to create the perfect working position. Due to the short T-Rex® upper arm of the NEXT Lite, only minimal depth is required when placed near a wall or separation panel. This allows the screen to be positioned further away from the user which is better for the eyes and also leaves more space for good ergonomic working posture. The smart internal cable management system ensures orderly routing of the cables. The DS20-425BL1 is equipped with an Easy-release VESA system for easy installation and comes with both desk clamp and grommet. The packaging of the NEXT Lite is 100% plastic free and entirely made from cardboard and paper.
Specifications
| Min. screen size (inch) | 11.6 |
|---|---|
| Max. screen size (inch) | 17.3 |
| Max. weight (kg) | 5 |
| Screens | 1 |
| Min. VESA | 75x75 mm |
| Max. VESA | 100x100 mm |
| VESA pattern | 75x75, 100x100 |
| Mount | Desk |
| Desk mount | Grommet, Clamp |
| Tilt (degrees) | +90°, -30° |
| Rotate (degrees) | 360° |
| Swivel (degrees) | +90°, -90° |
| Height adjustment | 18-38,5 cm |
| Width adjustment (cm) | 41,3 cm |
| Depth adjustment (cm) | 16,2-49,4 cm |
| Clamp range | 1-8 cm |
| Width (cm) | 46,5 cm |
| Depth (cm) | 49,4 cm |
| Height (cm) | 64,1 cm |
| Distance to wall (cm) | 16,2-49,4 cm |
| EAN code | 8717371449858 |
Use and tips
A laptop stand raises the screen to eye level and is used with a separate keyboard and mouse: that combination is what delivers the real postural benefit, since the laptop alone stays too low. Check the supported screen size and weight, and keep the ventilation openings clear.
Frequently asked questions
Is my screen compatible?
This model accepts 11.6 to 17.3 inch, 5 kg maximum, VESA 75x75 to 100x100. These three values have to be checked together: the screen size, the weight and the hole pattern on the back of the screen. If your screen has no VESA holes or if you are unsure, our contact page puts you in touch with our technical team.
What is the warranty?
Neomounts covers this product with a 5 year manufacturer warranty from the invoice date, for use in line with the instructions. The warranty covers manufacturing defects and mechanical parts, not damage caused by a load above the stated capacity.
Where are the assembly manual and the product sheet?
Neomounts provides the product sheet, the assembly manual, the line drawing and the safety sheet of this model free of charge: our Neomounts support page takes you straight to those documents.
Is the mounting hardware included?
The screws and the assembly instructions are supplied in the box. The anchors provided suit solid substrates; for a hollow partition, a metal stud frame or a suspended ceiling, plan fixings suited to your structure. Our contact page puts you in touch with our technical team to confirm your case.
