Highlights
- 65 pages per minute and 130 images per minute in duplex: both sides are captured in a single pass, at 300 as well as 200 dpi.
- 100-sheet feeder handling 27 to 413 g/m²: thin paper, plastic cards, business cards and long documents up to 6,096 mm.
- Production-grade reliability: 7,000-page daily duty cycle, ultrasonic double-feed sensor, ReadyScan LED technology with no warm-up.
- 1.5 inch LCD with push-scan jobs to email, network folder, FTP or print; Document Capture Pro 2.0 and Epson Scan 2 included.
- TWAIN, ISIS, SANE and WIA drivers: direct integration with mainstream document management and capture software.
Specifications
| Manufacturer reference | DS-870 (B11B250401) |
|---|---|
| EAN code | 8715946660813 |
| Type | A4 sheet-fed document scanner, single-pass duplex |
| Speed | 65 ppm / 130 ipm black and color (A4, 300 dpi) |
| Optical resolution | 600 x 600 dpi; output up to 1,200 dpi |
| Color depth | 30-bit input, 24-bit output |
| Feeder | 100 sheets; 27 to 413 g/m²; plastic and business cards |
| Paper sizes | A4, A5, A6, B5, B6, Letter, Legal; long documents up to 215.9 x 6,096 mm; A3 with carrier sheet |
| Daily duty cycle | 7,000 pages |
| Detection | Ultrasonic double-feed sensor, paper protection |
| Scan to | Email, network folder, FTP, software, print |
| File formats | PDF, JPEG, TIFF, PNG, BMP |
| Drivers | TWAIN, ISIS, SANE, WIA |
| Included software | Document Capture Pro 2.0, Epson Scan 2, Epson Device Admin |
| Connectivity | USB 3.2 Gen 1; optional Ethernet |
| Display | 1.5 inch (3.81 cm) LCD |
| Power consumption | 30 W scanning, 0.1 W off |
| Dimensions (W x D x H) and weight | 296 x 169 x 167 mm, 3.6 kg |
| Box contents | Scanner, AC adapter, cables, drivers and software |
| Origin | Indonesia |
| Manufacturer warranty | 12 months, extended to 36 months on-site after registration with Epson |
Consumables, maintenance parts and accessories
Maintenance parts
The feed roller kit (about 200,000 pages) will join the catalog with the full Epson batch and will then be linked to this page.
Usage
The DS-870 is built for mailroom, accounting and archive teams that digitize stacks of documents every day: up to 7,000 pages per day, in 100-sheet batches, from invoices and delivery notes to plastic cards.
Day to day: single-pass duplex scanning into your document management system via TWAIN or ISIS, push-scan jobs from the display (to email, network folder or FTP), long documents and receipts handled with the adjustable guides.
Good to know: the DS-870 connects to one workstation over USB 3.2; for direct network sharing an Ethernet dock is available as an option, and the DS-970 in the same series reaches 85 pages per minute.
Frequently asked questions
Does the DS-870 scan duplex?
Yes, in a single pass: both sides are captured simultaneously, at 65 pages per minute or 130 images per minute, in black and in color.
Does it work with document management software?
Yes: TWAIN, ISIS, SANE and WIA drivers are included, along with Document Capture Pro 2.0 for job profiles (barcode separation, automatic naming, indexed PDF export).
Where can I find drivers and the manual?
On our Epson support page, model DS-870: Windows and macOS drivers, user guide, Document Capture Pro.
